Wifi control LED STREET LIGHT
Advantages:
Lumileds 3030/5050 Chips.
Meanwell HLG Driver and Inventronics driver for 0-5V, 0-10V, PWM, Timer dimming.
Tempered Glass lens.
Type I, Type II, Type III optics for different width road lighting.
With Surge Projector to protect lamp from up to 10KV/10KA.
With Power Turn Off Protector to protect the personal safety.
With Imported Breather to keep the air pressure balance inside and outside the lamp, improving work performance, life of the lamp and prevent burst.
Big recessed structure design can be installed the MPPT remote control controller and wireless module to be a intelligent control system.
Full die-cast aluminum housing to prevent guano.
Snap-in type, easy installation by snap locking the two ends together, do not need tools to open or close the light cap.
Specification
| Model | ZGSM-LD120KM |
| LED Brand | Philips LUMILEDS® LUXEON 3030/5050 |
| Driver Brand | Non-dimmable: MeanWell HLG Driver | Dimmable: Inventronics Driver |
| Norminal Wattage | 120W |
| Input Voltage | 100-240V /277V AC 50 /60Hz |
| Power Efficiency | >90% |
| Power Factor | >0.95 |
| Lamp Rated Luminous Efficiency | >130 lm /w - 150 lm/w |
| Lamp Rated Lumen output | 15600 lm - 18000 lm |
| Color Rendering Index | Ra>70 |
| Color Temperature | 4000K (Nature White), 5000K (Pure White), 5700K (Cool White) |
| Photometric Type | 1M,2M,3M |
| Operating Temperature | 40 ºC to +50 ºC |
| Total Harmonic Distortion | < 20% |
| Lumen Maintenance | > 100,000 hours -L70, @25 ºC (77 ºF) |
| Materials | Die-cast aluminum;Tempered Glass |
| IP Rating | IP66 with test report |
| IK Rating | IK08 with test report |
| Certification | CE, ROHS, IOS9001, ISO14001, LM80 |
| Optional Function | 0-5V, 0-10V, PWM, Timer |
| Photocell Control | |
| Warranty | 7 years |
| Packing Details | |
| Fixture Weight | 8.2 kg |
| Packing Dimension | 785 X410 X170 mm |
| Packing Weight | 9.0 kg |
Application:
1.Residential Buildings, Home, Office, Meeting Room
2.School, Library, Factory, Warehouse
3.Hotel, Casino, Parking Garage, Hospital
4.Commercial Center, Supermarket, Shopping mall
Project picture
Factory show
AFTER-SALE SERVICE-7 years warranty
Hangzhou ZGSM Technology Co., Ltd ("ZGSM") warrants this ZGSM-branded hardware product against defects in
materials and workmanship under normal use for a period of SEVEN (7) YEAR from the date of purchase.ZGSM provides free repair or replacement within warranty period.
ZGSM shall charge against defeats by abnormal storage, usage, connection or change the structure or any components of the product.
Damage by thunder stroke over 6KV(L,N to FG) /4KV(L to N) will not covered by warranty based on IEC61000-4-5.
What can you get from us?
Excellent products (unique design, advance printing machine,strict quality control ) Factory direct sale (favorable and competitive price) Great service(OEM,ODM, after-sales services, fast delivery) Professional business consultation.
FAQ:
Q1. Can I have a sample order for led light?
A: Yes, we welcome sample order to test and check quality. Mixed samples are acceptable.
Q2. What is your main product line is made?
A:We mainly produce led application classes and industrial lighting fixtures. Including daily life indoor lighting and out-door lighting. (Led panel Light, Led flood Light, Led celling Light etc. )
Q3. Do you have any MOQ limit for led light order?
A: Low MOQ, 1pc for sample checking is available
Q4. How do you ship the goods and how long does it take to arrive?
A: We usually ship by DHL, UPS, FedEx or TNT. It usually takes 3-5 days to arrive. Airline and sea shipping also optional.
Q5. How to proceed an order for led light?
A: Firstly let us know your requirements or application. Secondly We quote according to your requirements or our suggestions. Thirdly customer confirms the samples and places deposit for formal order. Fourthly We arrange the production.
Q6. Is it OK to print my logo on led light product?
A: Yes. Please inform us formally before our production and confirm the design firstly based on our sample.
Q7: Do you offer guarantee for the products?
A: Yes, we offer 2-5 years warranty to our products.
Q8: How to deal with the faulty?
A: Firstly, Our products are produced in strict quality control system and the defective rate will be less than 0.2%. Secondly, during the guarantee period, we will send new lights with new order for small quantity. For defective batch products, we will repair them and resend them to you or we can discuss the solution i ncluding re-call according to real situation.
