Tool Less LED Road Light
Product Description
Features:
1. LUMILEDS 3030
2. Inventronics or Meanwell Driver with wide voltage: 100-240V /277V AC
3. Each module with 60-63 pcs LED chips
4. High luminous efficiency: 130 LM/W
5. More economical price.
| Specifications | |
| Model | ZGSM-LD200H5 |
| LED Brand | Philips LUMILEDS 3030 |
| Driver Brand | Meanwell / Inventronics |
| Norminal Wattage | 200W |
| LED Module Quantity | 4 modules |
| Input Voltage | 100-240/277VAC/DC24V |
| Power Efficiency | >90% |
| Power Factor | >0.95 |
| Lamp Rated Luminous Efficiency | >130 lm /w |
| Lamp Rated Lumen output | 2600 lm (Lumen tolerance +/- 5%) |
| Color Rendering Index | Ra>70 |
| Color Temperature | 3000, 4000, 5000 or 5700K |
| Photometric Type | Type I Medium;Type II Medium;Type III Medium,TypeV Short |
| Optimal Operating Temperature | 25℃ |
| Storage Temperatures | -40°C~50°C |
| Working Environment | Between-40°C~+50°C, 10%~90%RH |
| Total Harmonic Distortion | < 10% |
| Lumen Maintenance | > 75000 hours -L70, @25 ºC (77 ºF) |
| Body and Shell Materials | Anodized Aluminum |
| IP Rating | IP66 with test report |
| IK Rating | IK10 with test report |
| Certification | CE, ROHS, IOS9001, ISO14001, LM80,ENEC,CB |
| Optional Function | 1-10V DC or PWM Signal or Resistance Dimming |
| Timer/Photocell Control | |
| Warranty | 7 years |
| Packing Details | |
| Fixture Dimension | 650 x316 x136 mm |
| Fixture Weight | 8.2 kg |
| Packing Dimension | 705x370 x200 mm |
| Packing Weight | 9.6 kg |
1, Free sample service
Samples can be free.
Sample which we have in stock, will be sent to you within 1 working day.
OEM sample, will be sent to you within 3 working days.
2, Custom packaging service
No matter the inner packing or the outer carton.
We can design as your request.
3,Quick response
All requests will be reply within 12 hours.
