37W GS IEC62778 Light LED Straßenleuchten
The ZGSM L Series LED street lights are powered by dimmable Inventronics or non-dimmable Mean Well drivers that provide high performance regulation over a wide range of operating conditions. The LED drivers with exceptional operating efficiency and provide a constant-current output with a PF-corrected and low THD input. The dimmable Inventronics driver has built-in 0-5V/0-10V/PWM/Time dimming options. These LED drivers deliver high reliability with robust specifications for overcurrent, short-circuit, overvoltage and over-temperature protection. The electrical system is equipped with a surge protection device (SPD) which provides 10kV common surge (line-to-ground) and differential surge (line-to-line) mode protection.
The luminaires come with specifically designed die cast catenary mounting brackets with position locks for use with 6 to 12 mm diameter steel cables.
Product features
Modern geometric design complements a wide range of contemporary architectural settings.
Rugged die cast aluminum construction provides durability, strength and longevity.
Superior thermal management for high lumen maintenance, luminous efficacy and chromaticity stability.
LUXEON 3030 2D LEDs with superior light quality, high efficacy, and lifetime value.
Constant current LED drivers with high efficiency, high power factor and low harmonic distortion.
High efficiency optics ensures excellent uniformity, greater fixture spacing, homogeneous glare reduction, minimized light trespass and sky glow.
Corrosion resistant TGIC polyester powder coating provide excellent salt, humidity, fade resistance, and optimal color and gloss retention.
10kV SPD device protects the complete system against line surges, e.g. a lightning stroke.
Hinged housing with a tool-less latching system allowing easy entry.
IP66 ingress protection.
7-year warranty.
| Specifications | |||
| Model | ZGSM-LD37LM | ||
| LED Brand | Philips Lumileds 3030 2D | ||
| Driver Brand | MeaWell/Inventronics | ||
| Norminal Wattage | 37W | ||
| LED Quantity | 96 Units | ||
| Input Voltage | 100-240/277V AC, 50/60 Hz | ||
| Power Efficiency | >90% | ||
| Power Factor | >0.95 | ||
| Lamp Rated Luminous Efficiency | >130 lm /w | ||
| Lamp Rated Lumen output | 4,810 lm (Lumen tolerance +/- 5%) | ||
| Color Rendering Index | Ra>70 | ||
| Color Temperature | 3000, 4000, 5000 or 5700K | ||
| Photometric Type | Type I Medium, Type II Medium, Type III Medium, Type V Short | ||
